1.2 kg
| Input Connections | Balanced XLR/Jack Combo (Channel 1-2), Balanced ¼” Jack (Channel 3-4) |
| Output Connection | Balanced XLR (Main Out L-R), Stereo ¼” Jack (Phones) |
| Channel 1-2 Functions | +48V Phantom Power, Impedance switch (Line/Hi-Z), 2-Band EQ (80Hz/12kHz +/-15dB), Effect Send Level, Pan Position, Channel Volume, Peak Led Indicator |
| Channel 3-4 Functions | Impedance switch (+4/-10dB), 2-Band EQ (80Hz/12kHz +/-15dB), Effect Send Level, Pan Position, Channel Volume, Peak Led Indicator |
| USB Player Buttons | Up/Rewind, Down/Forward, Play/Pause/Enter, Menu |
| USB Player Functions | BT streaming, Music Player, Audio Recording, EQ-Curve Selection |
| USB Drive Format | FAT32 format – max 64GByte |
| Player File Formats | WAV, MP3, WMA, FLAC e streaming audio wireless BT |
| Recorder File Format | MP3 (48kHz/16bit @ 128Kbps) |
| Effect Functions | Echo Repetition Adjustment, Echo Delay Time Adjustment, Echo Level Adjustment |
| Level Meter | 2x6 LED Meter |
| Max Output Level | 3 Vrms |
| Frequency Response | +/-0.5dB, 20Hz-20kHz |
| Dynamic Range | 102dB |
| THD+N @ 1kHz | =0.003% |
| Stereo Crosstalk | 92dB |
| Power Requirements | DC 5V, 0.5A |
| Power Consumption | Max. 2.5W |
| Size (WxDxH) | 166 x 165 x 66 mm |
| Packing Size (WxDxH) | 300 x 208 x 87 mm |
| Net Weight | 0.9 kg |
| Gross Weight |
| 4 Total Channels | |
| 2 Mic/Line channels with noiseless preamp, combo connector, Hi-Z input for guitars, +48V Phantom Power, Peak Indicator | |
| 1 Stereo Line Channel with ¼” Jack inputs, +4/-10dB Pad Adapter and Peak Indicator | |
| USB Media Player and Recorder (WAV, MP3, WMA, FLAC and BT wireless audio streaming) | |
| 2-Band EQ for channels 1 and 2 | |
| Digital Echo Effect with Repetition, Delay and Level adjustment | |
| Media Player output level control | |
| Headphone monitor out with level control | |
| XLR Main Outputs with Master Level Control | |
| Stereo 6-Led VU Meter Bar | |
| Rugged and Lightweight Metal Case for Maximum Flexibility and Portability |
